IP Phones Huawei 7900 Series Available to Quote:

IP Phone 7910;
IP Phone 7950;

Expansion Module 7903X

Request a Quote
Description Specifications Additional materials

7900 series IP Phones with two 1GbE ports

General All
Interfaces
1
IP Phone 7910:
  • 2-Port 1GbE (RJ45);
  • 1-Port handset (RJ9);
  • 1-Port headset (RJ9)
IP Phone 7950:
  • 2-Port 1GbE (RJ45);
  • 1-Port handset (RJ9);
  • 1-Port USB;
  • 1-Port headset (RJ9/USB);
  • Support for 7903X expansion module
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
IP Phone 7910:
231 x 208 x 103
(9.09 x 8.18 x 4.05 in)
IP Phone 7950:
217 x 208 x 124
(8.54 x 8.18 x 4.88 in)
Expansion Module 7903X:
209 x 130 x 67.5
(8.22 x 5.11 x 2.63 in)
4
Maximum Weight (kg)
IP Phone 7910: 0.85 (1.87 lbs)
IP Phone 7950: 0.9 (1.98 lbs)
Expansion Module 7903X: 0.41 (0.90 lbs)
5
Environmental Conditions
6
Relative Humidity (%)

10 to 90

7
Operating Temperature (°C)

0 to 40 (32 to 104 °F)

8
Maximum Power Consumption (W)
IP Phone 7910: 3.84
IP Phone 7950: 6.49
Expansion Module 7903X: 3.0
9
WLAN
10
Wi-Fi: Not supported
Bluetooth: Bluetooth 2.1
11
Screen
12
IP Phone 7910:
2.83" TFT LCD;
Resolution: 320x240
IP Phone 7950:
5" TFT LCD;
Resolution: 800x400
Expansion Module 7903X:
5" TFT LCD;
Resolution: 480x800
13
Supported protocols
14

TCP/IP, SIP, SDP, UDP, RTP, RTCP, DHCP, DNS, PPPoE, HTTP, HTTPS, SNTP,  XCAP

15
Supported codecs
16
Voice codecs: G.711a/μ, G.722, G.722.1, G.722.2, G.729AB, iLBC, Opus, AAC-LD
Video codecs: Not supported
17
Power Supply Unit (PSU)
18
AC PSU
Type: Extrenal
Rated voltage range: 100 to 240 VAC, 50-60 Hz
Output: 5 VDC. 2 А
19
DC PSU
Type: PoE (802.3af)
