VP9600 series MCU for multipoint videoconferencing

General All

Interfaces

VP9630:	1-Port 10/100MbE (RJ45); 2-Port 1GbE (RJ45); 2-Port 1GbE (SFP); 1-Port console (RJ45); 2 AC PSU slots
VP9650:	2 Services Cards slots; 1 Control Cards slot; 2 AC/DC PSU slots
VP9660:	8 Services Cards slots; 2 Control Cards slots; 4 AC/DC PSU slots

Physical Parameters

Dimensions (HxWxD) (mm)

VP9630:

86.1 (2U) x 442 х 450

(3.39 (2U) x 17.4 x 17.72 in)

VP9650:

219.5 (5U) x 436 х 420

(8.64 (5U) x 17.17 x 16.54 in)

VP9660:

886.2 (20U) x 436 х 420

(34.89 (20U) x 17.16 x 16.54 in)

Maximum Weight (kg)

VP9630:	20 kg (44 lbs)
VP9650:	40 kg (88.18 lbs)
VP9660:	100 kg (220.46 lbs)

Environmental Conditions

Relative Humidity (%)

5 to 95

Operating Temperature (°C)

0 to 45 (32 to 113°F)

Maximum Power Consumption (W)

VP9630:	400
VP9650:	1100
VP9660:	3000

Supported protocols

Pv4/Pv6; TCP/IP; FTP/FTPS; RTP; RTCP; HTTP/HTTPS; SNMP; TELNET; SSH; DNS/DDNS; ITU-T H.323; H.320 (для VP9660 и VP9650); IETF SIP; H.221; H.225; H.235; H.242; H.243; H.245; H.281; H.283; H.460; TIP; FECC; RFC2833; DTMF; SRTP; TLS; T.140; NTP

Supported codecs

Voice codecs:	AAC-LD; AAC-LC; HWA-LD; G.722.1; G.722.1C; G.711; G.722; G.728; G.729A; G.729AB; G.719; iLBC
Video codecs:	ITU-T H.264; H.264 HP; H.264 SVC; H.263; H.263+; H.263++; H.261; ITU-T H.239; BFCP

Supported Resolution

QCIF; QVGA; CIF; VGA; 4CIF; SVGA(800x600); XGA(1024x768); SXGA+(1600x1200); 288P(512x288);

360P(640x360); 396P(704x400); 720P,1080P

Management

Telnet; SSH; Web; SNMP v1/v2/v3

Power Supply Unit (PSU)

AC PSU

Type:	Removable
Quantity:
VP9630:	1
VP9650:	2
VP9660:	2
Rated voltage range:	100 to 240 VAC, 50-60 Hz

DC PSU

Type:	Removable
Quantity:
VP9650:	2
VP9660:	2
Rated voltage range:	-48 to -60 VDC

Compatible Control Cards

Model Number

Description

ECCA:

Control card for VP9650.

1-Port 10/100MbE (RJ45);
2-Port 1GbE (RJ45);
2-Port 1GbE (SFP);
1-Port console (RJ45)

ECCB:

Control card for VP9660.

1-Port 10/100MbE (RJ45);
2-Port 1GbE (RJ45);
2-Port 1GbE (SFP);
1-Port console (RJ45)

Compatible Service Cards

Model Number	Description
ISDN board:	ISDN-board for VP9650, VP9660. 8-Port E1 (64 PRI); 1-Port 10/100MbE (RJ45); 2-Port 1GbE (RJ45); 2-Port 1GbE (SFP); 1-Port console (RJ45)
Media Board:	Media Board for VP9650, VP9660. Hardware resources: 24 ports at 1080p30 + 24 audio ports
RSE-M:	RSE-M board for VP9650, VP9660. 4 way dual streams recordings + 4 way 720p live streams + 500 way web viewers
