IP Camera Grandstream GXV3611IR

IP Camera Grandstream GXV3611IR_HD Available to Quote:

GXV3611IR_HD

Request a Quote

Description Specifications Additional materials

The GXV3611IR_HD is an indoor Infrared (IR) fixed dome IP camera with a high-definition 2.8mm lens – making it ideal for wide angle monitoring of nearby subjects in environments such as banks, hotels, retail, offices or building entrances.

General All

Interfaces

Audio interfaces:	1-Port 3.5mm line-in (IN) 1500 ohms; 1-Port 3.5mm line-out (OUT) 600 ohms
Network interfaces:	1-Port 10/100MbE (RJ45) PoE

Physical Parameters

Dimensions (HxD) (mm)

86 x 138

(3.38 x 5.43 in)

Maximum Weight (kg)

0,4 (0.88 lb)

Environmental Conditions

Relative Humidity (%)

10 to 90

Operating Temperature (°C)

0 to 45 (32 to 113°F)

Maximum power consumption (W)

6,80

IP rating compliance

IP66

Video Output

1080p, 720p

Supported protocols

TCP/UDP/IP, RTP/RTCP, RTSP, DHCP, DDNS, HTTP, HTTPS, SMTP, FTP, NTP

Supported codecs

Voice codecs:	G.711u/a
Video codecs:	H.264, MJPEG

Lens Specifications

Sensor

1MP 1/3” CMOS (1280 x 720)

Focal Length (mm)

f = 2,8

Lens Aperture

F1.8

Pan / Tilt

Pan range:	±176º
Tilt range:	±60º

Power Supply Unit (PSU)

AC PSU

Type:	External
Rated voltage range:	100 to 240 VAC, 50-60 Hz.
Output:	12 VDC / 0.5A

DC PSU

Type:

PoE (802.3af)

GXV3611_IR_HD Datasheet (en)
