IP camera Huawei IPC6225-VRZ-SP Available to Quote:

IPC6225-VRZ-SP

Request a Quote
Description Specifications Additional materials

Huawei IPC6225-VRZ-SP - IP camera provides high-quality images even in poor lighting conditions

General All
Interfaces
1
Audio interfaces:
  • 1-Port 3.5mm line-in (IN) and line-out (OUT)
Network interfaces:
  • 1-Port 10/100MbE (RJ45)
Common interfaces:
  • 1-Port RS485 (PELCO-P/D protocol);
  • 2-Channel alarm-in;
  • 2-Channel alarm-out;
  • 1-Channel CVBS output (BNC);
  • 1 SD card slot



2
Physical Parameters
3
Dimensions (HxWxD) (mm)

120 x 128,1 x 353,6

(4.72 x 5.03 x 13.89 in)

4
Maximum Weight (kg)

1,4 (3.08 lb)

5
Environmental Conditions
6
Relative Humidity (%)

5 to 95

7
Operating Temperature (°C)

-40 to +60 (-40 to 140°F)

8
Maximum power consumption (W)

16,3

9
IP rating compliance

IP66

10
Video Output
11

1080p

12
Supported protocols
13

TCP, UDP, IPv4, DHCP, DNS, ICMP, IGMP, HTTP, HTTPS, SFTP, RTP, RTSP, RTCP, SIP, ARP, TLS, NTP, SNMP(V1/V2/V3), 802.1x, QoS, DDNS

14
Supported codecs

Voice codecs:

G.711u/a; G.726; OPUS

Video codecs:

H.265; H.264; MJPEG
15
Lens Specifications
16
Sensor

2,0 МP 1/2.8" CMOS (1920 x 1080)

17
Zoom

Optical: 4.3x

18
Focal Length (mm)

f = 2.8 to 12

19
Lens Aperture

F1.4

20
Maximum Field of View
Horizontal: 34° to 86°
Vertical: 18° to 47°
21
Power Supply Unit (PSU)
22
AC PSU
Type: External
Rated voltage range: 24 VAC
23
DC PSU
Type: External, PoE (802.3at)
Rated voltage range:

12 VDC, 24 VDC

24
