IP Camera Huawei IPC6324-MIR

IP Camera Huawei IPC6324-MIR Available to Quote:

IPC6324-MIR

Request a Quote

Description Specifications Additional materials

IPC6324-MIR - IP camera provides high-quality images even in poor lighting conditions

General All

Interfaces

Audio interfaces:	Built-in microphone
Network interfaces:	1-Port 10/100MbE (RJ45)
Common interfaces:	1-Channel alarm-in; 1-Channel alarm-out; 1-Channel CVBS (BNC); 1 SD card slot

Physical Parameters

Dimensions (HxD)

59 x 107

(2.32 x 4.21 in)

Maximum Weight (kg)

0,4 (0.88 lb)

Environmental Conditions

Relative Humidity (%)

5 to 95

Operating Temperature (°C)

-20 to +60 (-4 to -140°F)

Maximum power consumption (W)

8,3

IP rating compliance

IP66

Video Output

1920 x 1080

Supported protocols

TCP, UDP, IPv4, DHCP, DNS, ICMP, IGMP, HTTP, HTTPS, SFTP, RTP, RTSP, RTCP, SIP, ARP, TLS, NTP, SNMP(V1/V2/V3), 802.1x, QoS, DDNS

Supported codecs

Voice codecs:	G.711u/a; G.726; OPUS
Video codecs:	H.265; H.264; MJPEG

Lens Specifications

Sensor

2.0MP 1/2.7" CMOS (1920H x 1080V)

Focal Length

f = 2,8 to 6,0

Lens Aperture

F2.2

Maximum Field of View

Power Supply Unit (PSU)

AC PSU

Not supported

DC PSU

Type:	External, PoE (802.3at)
Rated voltage range:	12VDC
