IP camera Huawei IPC6625-Z30-S

End-of-Sale.

Please see "Similar Products" below.

Description Specifications Additional materials

The camera IPC6625-Z30-S  is a professional solution for video surveillance systems. Huawei cameras meet the highest requirements of professional security systems and allow you to create video surveillance systems of any scale and complexity.

IPC6625-Z30-S - this is a 2 megapixel dome camera uses a 1 / 2.8-inch progressive scan CMOS sensor and H.265 encoding technology. Built-in intelligent infrared lamp can reach up to 150 meters distance.

General All
Interfaces
1
Audio interfaces: Not supported
Network interfaces:
  • 1-Port 10/100MbE (RJ45)
Common interfaces:
  • 4-Channel alarm-in;
  • 1-Channel alarm-out;
  • 1 SD card slot
2
Physical Parameters
3
Dimensions (HxWxD) (mm)

236,0 х 327,1

(9.29 x 12.87 in)

4
Maximum Weight (kg)

4,50 (9.92 lb)

5
Environmental Conditions
6
Relative Humidity (%)

5 to 95

7
Operating Temperature (°C)

-40 to +60 (-40 to +140°F)

8
Maximum power consumption (W)

62,1

9
IP rating compliance

IP66

10
Video Output
11

1920 x 1080

12
Supported protocols
13

TCP, UDP, IPv4, DHCP, DNS, ICMP, IGMP, HTTP, HTTPS, SFTP, RTP, RTSP, RTCP, SIP, ARP, TLS, NTP, SNMP(V1/V2/V3), 802.1x, QoS, DDNS

14
Supported codecs
Voice codecs:

Not supported

Video codecs: H.265; H.264; MJPEG
15
Lens Specifications
16
Sensor

2.0 МP 1/2.8" (1920H x 1080V)

17
Zoom
Optical: 30x
Digital: 16x
18
Focal Length (mm)

f = 4,5 to 135

19
Lens Aperture

F1.6

20
Maximum Field of View
Horizontal: 2.67° to 60.89°
Vertical:

1.51° to 37.34°



21
Power Supply Unit (PSU)
22
AC PSU
Type: External
Rated voltage range: 24VAC
23
DC PSU
Type: External
Rated voltage range: 24VDC
24
