Request a QuoteThe Aruba HPE 330 Series multifunction wireless Access Points provide the best Wi-Fi quality for 802.11ac Wave 2, while enhancing the usability and comfort of mobile device users.
The 330 Series Access points support data transfer at 1733 Mbit/s in the 5 GHz band and 800 Mbit/s in the 2.4 GHz band.
The integrated HPE Smart Rate port provides inbound channel up to 5 Gb/s.
IAP-334: |
|
AP-334: |
|
IAP-335: |
|
AP-335: |
|
52 x 225 х 224
(2.0 x 8.9 x 8.9 in)
1,15 (2.53 lbs)
5 to 95
0 to 50 (32 to 122°F)
25,3
Indoor
IAP-334:
AP-334:
|
external |
IAP-335:
AP-335:
|
internal
|
Wall / Ceiling mounting
802.11b:
|
Direct-sequence spread-spectrum (DSSS);
|
802.11a/g/n/ac:
|
Orthogonal frequency-division multiplexing (OFDM)
|
802.11n/ac:
|
802.11n: 4×4 MIMO with up to four spatial streams;
802.11ac: 4×4 MIMO with up to four spatial streams;
|
Bluetooth Low Energy (BLE) radio:
|
4 dBm transmit power (class 2) and -91 dBm receive sensitivity. Integrated antenna, 5.1 dBi (AP334/IAP334) or 2.2 dBi (AP335/IAP335) gain (30 degrees downtilt)
|
AP-334: AP-335: |
Aruba Mobility Controller |
IAP-334: IAP-335: |
Instant AP |
Type: | External |
Quantity: | 1 |
Rated voltage range: | 100 to 240 VAC, 50-60 Hz. |
Type: | PoE+ (802.3at) |
Quantity: | 1 |
Rated voltage range: | -48 VDC |
