Controllers Aruba 7200 Series
Controllers Aruba 7200 Series Available to Quote:
7205; 7210
7220; 7240XM
End-of-Sale: 7240
 Request a Quote
Description Specifications Additional materials

Controllers Aruba 7200 Series

General All
Interfaces
1
7205:
  • 2-Port 10GbE (SFP+);
  • 4-Port combo 1GbE (RJ45)/(SFP);
  • 1-Port USB;
  • 1-Port console (RJ45)/(miniUSB)
7210:
  • 4-Port 1/10GbE (SFP/SFP+);
  • 2-Port combo 1GbE (RJ45)/(SFP);
  • 1-Port USB;
  • 1-Port console (RJ45)/(miniUSB)
7220:
  • 4-Port 1/10GbE (SFP/SFP+);
  • 2-Port combo 1GbE (RJ45)/(SFP);
  • 1-Port USB;
  • 1-Port console (RJ45)/(miniUSB)
7240 :
  • 4-Port 1/10GbE (SFP/SFP+);
  • 2-Port combo 1GbE (RJ45/SFP);
  • 1-Port USB;
  • 1-Port console (RJ45)/(miniUSB)
7240XM:
  • 4-Port 1/10GbE (SFP/SFP+);
  • 2-Port combo 1GbE (RJ45)/(SFP);
  • 1-Port USB;
  • 1-Port console (RJ45)/(miniUSB)
  • 16GB DRAM
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
7205:
44 (1U) x 334 х 442
(1.75 (1U) x 13.13 x 17.38 in)
7210:
7220:
7240:
7240XM:
44 (1U) x 445 х 445
(1.75 (1U) x 17.5 x 17.5 in)
4
Maximum Weight (kg)
7205:
4,95 (10.19 lbs)
7210:
7220:
7240:
7240XM:
7,45 (16.43 lbs)
5
Environmental Conditions
6
Relative Humidity (%)

5 to 95

7
Operating Temperature (°C)

0 to 40 (32 to 104°F)

8
Maximum Power Consumption (W)
7205: 75,2
7210: 110
7220: 125

7240:

7240XM:

 165
9
Acoustic Noise (dB)
7205:
49,0
7210:
7220:
46,9
7240:
7240XM:
54,7
10
Maximum Access Points
11
Access Points (AP)
7205: 256
7210: 512
7220: 1,024
7240 / 7240XM: 2,048

Remote Access Points (RAP)
7205: 256
7210: 512
7220: 1,024
7240 / 7240XM: 2,048
12
Maximum IPSec Sessions Supported
13
7205: 4096
7210: 16 384
7220: 24 576

7240:

7240XM:

 32 768
14
Power Supply Unit (PSU)
15
AC PSU
Type:
7205: Built-in
7210:
7220:
7240:
7240XM:
 Removable
Quantity:
7205: 1
7210:
7220:
7240:
7240XM:
 2
Rated voltage range: 100 to 240 VAC, 50-60 Hz.
16
DC PSU
Type:
7205: Not supported
7210:
7220:
7240:
7240XM:
 Removable
Quantity:
7205: Not supported
7210:
7220:
7240:
7240XM:
 2
Rated voltage range:
7205: Not supported
7210:
7220:
7240:
7240XM:
 -48 to -60 VDC
17

MC7200 Datasheet (en)
