Switches Huawei S7700 Series Available to Quote:
S7703;
S7706;
S7712
Request a Quote
Description Specifications Additional materials

Huawei S7700 Series PoE Switches with Intelligent Routing for data centers and enterprise networks.

The S7700 switches provide intelligent multi-tier switching technologies for service optimization, support MPLS/VPN, and comprehensive QoS policies.

General All
Interfaces
1
S7703:
  • 2 Control Card slots (MPU);
  • 3 Service Card slots (LPU)
S7706:
  • 2 Control Card slots (SRU);
  • 6 Service Card slots (LPU)
S7712:
  • 2 Control Card slots (SRU);
  • 12 Service Card slots (LPU)
2
Physical Parameters
3
Dimensions (HxWxD) (mm)
S7703:
175 (4U) x 442 x 489
(6.88 (4U) x 17.40 x 19.25 in)
S7706:
442 (10U) x 442 x 489
(17.40 (10U) x 17.40 x 19.25 in)
S7712:
664 (15U) x 442 x 489
(26.14 (15U) x 17.40 x 19.25 in)
4
Maximum Weight (kg)
S7703: 10 (22.04 lbs)
S7706: 15 (33.06 lbs)
S7712: 37 (81.57 lbs)
5
Environmental Conditions
6
Relative Humidity (%)

5 to 95

7
Operating Temperature (°C)

0 to 45 (0 to 113 °F)

8
Maximum Power Consumption (W)
S7703: 1000
S7706: 2200
S7712: 4200
9
Acoustic noise (dB)

72

10
Performance
11
Switching Bandwidth (Tbit/s)
S7703: 1.92
S7706: 3.84
S7712: 3.84
12
Forwarding Rate (Mp/s)
S7703: 1440
S7706: 2880
S7712: 2880
13
MAC Address Table (entries)
Card Series Specifications
SA, SC, EA, EE, FA, FC: 32,000
ED: 512,000 (in enhanced-mac mode)
EC, BC, X2S: 128,000 (in enhanced-mac mode)
EE: 688,000 (in enhanced-mac mode)
X1E, X2H: 1M (in enhanced-mac mode)
X2E: 384,000 (in enhanced-mac mode)
EH1D2X48SEC0: 288,000 (in enhanced-mac mode)
14
ARP Table (entries)
Card Series Specifications
EE: 128,000 (in 128k-arp mode)
SA, SC, EA, EE, FA, FC: 32,000
EC, BC, ED: 16,376
X2S: 64,000 entries (in enhanced-arp mode)
X1E: 256,000
X2E, X2H: 256,000 (in enhanced-arp mode)
EH1D2X48SEC0: 128,000 (in enhanced-arp mode)
15
Layer 2 Features
16
VLAN

IEEE 802.1Q: 4094.  GVRP; QinQ; VLAN Translation

17
Layer 2 Reliability

STP/RSTP/MSTP; VBST; RRPP; ERPS (G.8032); Switch Cluster System (CSS)

18
Multicast
19
IGMP snooping: v1/v2/v3
IGMP groups: 4096
Multicast VLAN (MVR): Supported
Multicast Routing: PIM-DM; PIM-SM; PIM-SSM; MSDP
20
Layer 3 features
21
Routing Table (routes)
Card Series Specifications
FIB IPv4:
SA, SC, EA, EE, FA, FC: 16,000
EC, BC: 128,000 (in enhanced-ipv4 mode)
ED, EE: 512,000 (in enhanced-ipv4 mode)
X2S: 128,000 (in enhanced-ipv4 mode) (with FIB license)
X1E, X2H: 1M (in enhanced-ipv4 mode) (with FIB license)
X2E: 256,000 (in enhanced-ipv4 mode) (with FIB license)
EH1D2X48SEC0: 128,000 (in enhanced-ipv4 mode)

FIB IPv6:
SA, SC, EA, EE, FA, FC: 8000
EC, BC: 64,000 (in enhanced-ipv6 mode)
ED, EE: 256,000 (in enhanced-ipv6 mode)
X2S: 32,000 (in enhanced-ipv6 mode)
X1E: 464,000 (in enhanced-ipv6 mode) (with FIB license)
X2H: 512,000 (in enhanced-ipv6 mode) (with FIB license)
X2E: 128,000 (in enhanced-ipv6 mode) (with FIB license)
EH1D2X48SEC0: 80,000 (in enhanced-ipv4 mode)
22
IP Routing

Static Routing; RIPv1/2; OSPFv2; IS-IS; BGP; MBGP; VRRP

23
MPLS / VPN
24

Supported (with MPLS license). MPLS LDP; L2VPN; MPLS-TE; L3VPN; VPLS; GRE

25
Security
26
Local AAA: Supported
RADIUS, TACACS+: Supported
PPPoE Server: Supported (with license and X-type cards)
DHCP Server: Supported
DHCP Relay option82: Supported
DHCP Snooping: Supported
Loop detection: Supported
IP Source Guard: Supported
Bandwidth Limit: Supported
Broadcast, multicast, unknown unicast suppression: Supported
27
Management
28

Telnet; SSH; Web; LLDP; sFlow; SNMP v1/v2/v3; RMON; Syslog; NTP

29
Power Supply Unit (PSU)
30
AC PSU
Type: Removable
Quantity:
S7703: 3
S7706: 8
S7712: 8
Rated voltage range: 100 to 240 VAC; 47-63 Hz
31
DC PSU
Type: Removable
Quantity:
S7703: 3
S7706: 8
S7712: 8
Rated voltage range: -48 to -60 VDC
32
PoE (Power over Ethernet)
33
PoE budget (W)
S7703: 2200
S7706: 8800
S7712: 8800
34
Compatible Control Cards
35
Model Number
Description
ES0D00SRUA00:
SRUA Control Card for S7706, S7712.
  • 1 expansion slot for subcard;
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 10/100MbE (RJ45)
ES1D2SRUAC00:
SRUA Control Card for S7706, S7712.
  • 1 expansion slot for subcard;
  • 2-Port GE (SFP) (Reserved);
  • 1-Port USB;
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 10/100MbE (RJ45)
ES1D2SRUH000:
SRUH Control Card for S7706, S7712.
  • 1 expansion slot for subcard;
  • 2-Port GE (SFP) (Reserved);
  • 1-Port USB;
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 10/100MbE (RJ45)
ES0D00SRUB00:
SRUB Control Card for S7706, S7712.
  • 1 expansion slot for subcard;
  • 2-Port BITS;
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 10/100MbE (RJ45)
ES1D2SRUE000:
SRUE Control Card for S7706, S7712.
  • 1 expansion slot for subcard;
  • 2-Port GE (SFP) (Reserved);
  • 1-Port USB;
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 10/100MbE (RJ45)
ES0D00MCUA00:
MCUA Control Card for S7703.
  • 1-Port RS485 (Reserved);
  • 1-Port MON (Reserved);
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 10/100MbE (RJ45)
ES1D2MCUAC00:
MCUA Control Card for S7703.
  • 2-Port BITS;
  • 1-Port RS485 (Reserved);
  • 1-Port MON (Reserved);
  • 1-Port console (RJ45);
  • 1-Port out-of-band management 10/100MbE (RJ45)


Subcards for the Control Cards
ES0D00FSUA00:
Subcard. Can be installed in the ES0D00SRUA00, ES0D00SRUB00, ES1D2SRUE000, ES1D2SRUH000 Control Cards.
  • Provides OAM and BFD
LE0D00CKMA00:
Subcard. Can be installed in the ES1D2SRUAC00, ES0D00SRUB00, ES1D2MCUAC00 Control Cards.
  • Provides Sync Ethernet Clock and IEEE1588
ES02VSTSA:
Subcard. Can be installed in the ES0D00SRUA00, ES1D2SRUAC00, ES0D00SRUB00 Control Cards.
  • Provides Sync Ethernet Clock and IEEE1588
ES1D2VS04000:
Subcard. Can be installed in the ES1D2SRUH000 and ES1D2SRUE000 Control Cards.
  • Provides four 16GE SR4 ports for CSS
36
Compatible Centralized Monitoring Unit (CMU) Cards
37
Model Number
Description
EH1D200CMU00:
Centralized Monitoring Unit Card for S7706 and S7712.
  • Manages system power modules and fan modules
38
Value Added Services Cards
Model Number
Description
LE0D0VAMPA00:
Value Added Services Card for S7703, S7706, S7712.
  • Provides VAS services such as load balancing, NAT, IPSec, NetStream
39
Open Service Platform Unit Cards
Model Number Description
EH1D2PS00P00:
Open Service Platform Unit for S7703, S7706, S7712.
  • ОS: VMware. Supports Intrusion Prevention System (IPS) software
40
Next-Generation Firewall (NGFW) Cards
Model Number Description
ET1D2FW00S00: Firewall, NAT, VPN. Card Performance: 10G
ET1D2FW00S01: Firewall, NAT, VPN. Card Performance: 20G
ET1D2FW00S02: Firewall, NAT, VPN. Card Performance: 40G
41
IPS (Intrusion Prevention System) Cards
Model Number Description
ET1D2IPS0S00: Supports IPS
42
Compatible Access Points Management Cards
Model Number
Description
ACU2:
Access Points management Card for S7703, S7706, S7712.
  • 128 AP control resource included
43
Compatible Service Cards
44
1GbE Service Cards
Model Number
Description
ES0D0G24SA00:
1GbE service card for S7703, S7706, S7712.
  • 24-Port 100/1000MbE (SFP)
ES0D0G24SC00:
1GbE service card for S7703, S7706, S7712.
  • 24-Port 100/1000MbE (SFP)
ES1D2G24SED0:
1GbE service card for S7703, S7706, S7712.
  • 24-Port 100/1000MbE (SFP)
ES0DG24TFA00:
1GbE service card for S7703, S7706, S7712.
  • 24-Port 1GbE (RJ45)
ES0D0G48VA00:
1GbE service card for S7703, S7706, S7712.
  • 48-Port 1GbE (RJ45) PoE
ES0D0G48TA00:
1GbE service card for S7703, S7706, S7712.
  • 48-Port 1GbE (RJ45)
ES0D0G48TC00:
1GbE service card for S7703, S7706, S7712.
  • 48-Port 1GbE (RJ45)
ES1D2G48TED0:
1GbE service card for S7703, S7706, S7712.
  • 48-Port 1GbE (RJ45)
ES0DG48TFA00:
1GbE service card for S7703, S7706, S7712.
  • 48-Port 1GbE (RJ45)
ES1D2G48TX1E:
1GbE service card for S7703, S7706, S7712.
  • 48-Port 1GbE (RJ45)
ES1D2G48TBC0:
1GbE service card for S7703, S7706, S7712.
  • 48-Port 1GbE (RJ45)
ES0D0G48SA00:
1GbE service card for S7703, S7706, S7712.
  • 48-Port 100/1000MbE (SFP)
ES0D0G48SC00:
1GbE service card for S7703, S7706, S7712.
  • 48-Port 100/1000MbE (SFP)
ES1D2G48SED0:
1GbE service card for S7703, S7706, S7712.
  • 48-Port 100/1000MbE (SFP)
ES1D2G48SFA0:
1GbE service card for S7703, S7706, S7712.
  • 48-Port 100/1000MbE (RJ45)
ES1D2G48SBC0:
1GbE service card for S7703, S7706, S7712.
  • 48-Port 100/1000MbE (SFP)
ES1D2G48SX1E:
1GbE service card for S7703, S7706, S7712.
  • 48-Port 100/1000MbE (SFP)



45
1GbE Combo Service Cards
Model Number Description
ES0D0G24CA00:
1GbE combo service card for S7703, S7706, S7712.
  • 16-Port 100/1000MbE (SFP);
  • 8-Port combo 1GbE (RJ45/SFP)
ES0DG48CEAT0:
1GbE combo service card for S7703, S7706, S7712.
  • 36-Port 1GbE (RJ45);
  • 12-Port 100/1000MbE (SFP)
46
10GbE Service Cards
Model Number
Description
ES0D0X2UXA00:
10GbE service card for S7703, S7706, S7712.
  • 2-Port 10GbE (XFP)
ES0D0X2UXC00:
10GbE service card for S7703, S7706, S7712.
  • 2-Port 10GbE (XFP)
ES1D2X02XEC1:
10GbE service card for S7703, S7706, S7712.
  • 2-Port 10GbE (XFP)
ES0D0X4UXA00:
10GbE service card for S7703, S7706, S7712.
  • 4-Port 10GbE (XFP)
ES0D0X4UXC00:
10GbE service card for S7703, S7706, S7712.
  • 4-Port 10GbE (XFP)
ES1D2X04XEC1:
10GbE service card for S7703, S7706, S7712.
  • 4-Port 10GbE (XFP)
ES1D2X04XED0:
10GbE service card for S7703, S7706, S7712.
  • 4-Port 10GbE (XFP)
ES1D2X08SED4:
10GbE service card for S7703, S7706, S7712.
  • 8-Port 10GbE (SFP+)
ES1D2X08SED:
10GbE service card for S7703, S7706, S7712.
  • 8-Port 10GbE (SFP+)
ES0D0X12SA00:
10GbE service card for S7703, S7706, S7712.
  • 12-Port 10GbE (SFP+)
ES1D2X16SFC0:
10GbE service card for S7703, S7706, S7712.
  • 16-Port 10GbE (SFP+)
ES1D2X16SSC2:
10GbE service card for S7703, S7706, S7712.
  • 16-Port 10GbE (SFP+)
ES1D2X32SSC0:
10GbE service card for S7703, S7706, S7712.
  • 32-Port 10GbE (SFP+)
ES1D2X32SX2E:
10GbE service card for S7703, S7706, S7712.
  • 32-Port 10GbE (SFP+)
ES1D2X32SX2S:
10GbE service card for S7703, S7706, S7712.
  • 32-Port 10GbE (SFP+)
ES1D2X40SFC0:
10GbE service card for S7703, S7706, S7712.
  • 40-Port 10GbE (SFP+)
ES1D2X48SX2S:
10GbE service card for S7703, S7706, S7712.
  • 48-Port 10GbE (SFP+)



47
10GbE Combo Service Cards
Model Number
Description
ES0D0T24XA00:
10GbE combo service card for S7703, S7706, S7712.
  • 2-Port 10GbE (XFP);
  • 24-Port 1GbE (RJ45)
ES0D0S24XA00:
10GbE combo service card for S7703, S7706, S7712.
  • 2-Port 10GbE (XFP);
  • 24-Port 100/1000MbE (SFP)
ES1D2S24XEC0:
10GbE combo service card for S7703, S7706, S7712.
  • 2-Port 10GbE (XFP);
  • 24-Port 100/1000MbE (SFP)
ES1D2S04SX1E:
10GbE combo service card for S7703, S7706, S7712.
  • 4-Port 10GbE (SFP+);
  • 24-Port 100/1000MbE (SFP);
  • 8-Port combo 1GbE (RJ45/SFP)
ES1D2S08SX1E:
10GbE combo service card for S7703, S7706, S7712.
  • 8-Port 10GbE (SFP+);
  • 8-Port 100/1000MbE (SFP);
  • 8-Port 1GbE (RJ45)
ES1D2S24SX2E:
10GbE combo service card for S7703, S7706, S7712.
  • 24-Port 10GbE (SFP+);
  • 8-Port 1GbE (SFP)
ES1D2S24SX2S:
10GbE combo service card for S7703, S7706, S7712.
  • 24-Port 10GbE (SFP+);
  • 8-Port 1GbE (SFP)
ES1D2S16SX2E:
10GbE combo service card for S7703, S7706, S7712.
  • 16-Port 10GbE (SFP+);
  • 16-Port 1GbE (SFP)
ES1D2S16SX2S:
10GbE combo service card for S7703, S7706, S7712.
  • 16-Port 10GbE (SFP+);
  • 16-Port 1GbE (SFP)
48
40GbE Service Cards
Model Number
Description
ES1D2L02QFC0:
40GbE service card for S7703, S7706, S7712.
  • 2-Port 40GbE (QSFP+)
ES1D2L08QX2E:
40GbE service card for S7703, S7706, S7712.
  • 8-Port 40GbE (QSFP+)
49
40/100GbE Service Cards
Model Number Description
ES1D2H02QX2S:
40/100GbE service card for S7703, S7706, S7712.
  • 2-Port 100GbE (QSFP28);
  • 2-Port 40GbE (QSFP+)
ES1D2H02QX2E:
40/100GbE service card for S7703, S7706, S7712.
  • 2-Port 100GbE (QSFP28);
  • 2-Port 40GbE (QSFP+)
50
100GbE Service Cards
Model Number
Description
ES1D2C02FEE0:
100GbE service card for S7703, S7706, S7712.
  • 2-Port 100GbE (CFP)
ES1D2C04HX2E:
100GbE service card for S7703, S7706, S7712.
  • 4-Port 100GbE (QSFP28)
ES1D2C04HX2S:
100GbE service card for S7703, S7706, S7712.
  • 4-Port 100GbE (QSFP28)
51
Similar Products
Recently viewed
Agree
This website uses cookies. By continuing to browse the website you are agreeing to accept of cookies Privacy Policy
