IP camera Huawei IPC6385-VRZ Available to Quote:

IPC6385-VRZ

Request a Quote
Description Specifications Additional materials

Huawei IPC6385-VRZ - IP camera provides high-quality images even in poor lighting conditions

General All
Interfaces
1
Audio interfaces:
  • 1-Port line-in (3.5 mm)
Network interfaces:
  • 1-Port 10/100MbE (RJ45)
Common interfaces:
  • 1-Channel alarm-in;
  • 1-Channel alarm-out;
  • 1-Channel CVBS (BNC);
  • 1 SD card slot



2
Physical Parameters
3
Dimensions (HxD) (mm)

112,5 x 135

(4.40 x 5.31 in)

4
Maximum Weight (kg)

1,20 (2.64 lb)

5
Environmental Conditions
6
Relative Humidity (%)

5 to 95

7
Operating Temperature (°C)

-40 to +60 (-40 to 140°F)

8
Maximum power consumption (W)

17,5

9
IP rating compliance

IP66

10
Video Output
11

3840 x 2160

12
Supported protocols
13

TCP, UDP, IPv4, DHCP, DNS, ICMP, IGMP, HTTP, HTTPS, SFTP, RTP, RTSP, RTCP, SIP, ARP, TLS, NTP, SNMP(V1/V2/V3), 802.1x, QoS, DDNS

14
Supported codecs
Voice codecs: G.711u/a; G.726; OPUS
Video codecs: H.265; H.264; MJPEG
15
Lens Specifications
16
Sensor

8.0МP 1/2.5" CMOS (3840H x 2160V)

17
Focal Length (mm)

f =  4,1 to 12,8

18
Lens Aperture

F1.53 to F3.3

19
Maximum Field of View
Horizontal: 28.18° to 87.76°
Pan: 0° to 356°
Tilt: 0° to 75°
Rotation: 0° to 356°
20
Power Supply Unit (PSU)
21
AC PSU

Not supported

22
DC PSU
Type: External, PoE (802.3at)
Rated voltage range: 12VDC, 24VDC
23
